DC SC2020
6.3.15 NVM 755_Process Control 4 List
Version 1.1
General
755-392 Standard LPH[M] 677 0 2046 Standard LPH - O O
755-393 Standard LPH[C] 677 0 2046 Standard LPH - O O
755-394 Standard LPH[K] 677 0 2046 Standard LPH - O O
755-395 LPH_PS Correction Coefficient [Y][PS0] 1024 0 65535 LPH_PS Correction Coefficient - O O
755-396 LPH_PS Correction Coefficient [Y][PS1] 1024 0 65535 LPH_PS Correction Coefficient - O O
755-397 LPH_PS Correction Coefficient [M][PS0] 1024 0 65535 LPH_PS Correction Coefficient - O O
755-398 LPH_PS Correction Coefficient [M][PS1] 1024 0 65535 LPH_PS Correction Coefficient - O O
755-399 LPH_PS Correction Coefficient [C][PS0] 1024 0 65535 LPH_PS Correction Coefficient - O O
755-400 LPH_PS Correction Coefficient [C][PS1] 1024 0 65535 LPH_PS Correction Coefficient - O O
755-401 LPH_PS Correction Coefficient [K][PS0] 1024 0 65535 LPH_PS Correction Coefficient - O O
755-402 LPH_PS Correction Coefficient [K][PS0] 1024 0 65535 LPH_PS Correction Coefficient - O O
755-403 Delta LPH Speed Correction Amount [Y][PS0] 0 -1024 1023 Correction Amount of LPH_PS Correction Coefficient - O O
755-404 Delta LPH Speed Correction Amount [Y][PS1] 0 -1024 1023 Correction Amount of LPH_PS Correction Coefficient - O O
755-405 Delta LPH Speed Correction Amount [M][PS0] 0 -1024 1023 Correction Amount of LPH_PS Correction Coefficient - O O
755-406 Delta LPH Speed Correction Amount [M][PS1] 0 -1024 1023 Correction Amount of LPH_PS Correction Coefficient - O O
755-407 Delta LPH Speed Correction Amount [C][PS0] 0 -1024 1023 Correction Amount of LPH_PS Correction Coefficient - O O
755-408 Delta LPH Speed Correction Amount [C][PS1] 0 -1024 1023 Correction Amount of LPH_PS Correction Coefficient - O O
755-409 Delta LPH Speed Correction Amount [K][PS0] 0 -1024 1023 Correction Amount of LPH_PS Correction Coefficient - O O
755-410 Delta LPH Speed Correction Amount [K][PS1] 0 -1024 1023 Correction Amount of LPH_PS Correction Coefficient - O O
755-411 P_LUT[Y][LUT0] 25 0 511 Point LUT Value of 6 points - O O
755-412 P_LUT[Y][LUT1] 36 0 511 Point LUT Value of 6 points - O O
755-413 P_LUT[Y][LUT2] 76 0 511 Point LUT Value of 6 points - O O
755-414 P_LUT[Y][LUT3] 112 0 511 Point LUT Value of 6 points - O O
755-415 P_LUT[Y][LUT4] 148 0 511 Point LUT Value of 6 points - O O
755-416 P_LUT[Y][LUT5] 255 0 511 Point LUT Value of 6 points - O O
755-417 P_LUT[M][LUT0] 25 0 511 Point LUT Value of 6 points - O O
755-418 P_LUT[M][LUT1] 36 0 511 Point LUT Value of 6 points - O O
755-419 P_LUT[M][LUT2] 76 0 511 Point LUT Value of 6 points - O O
755-420 P_LUT[M][LUT3] 112 0 511 Point LUT Value of 6 points - O O
755-421 P_LUT[M][LUT4] 148 0 511 Point LUT Value of 6 points - O O
755-422 P_LUT[M][LUT5] 255 0 511 Point LUT Value of 6 points - O O
755-423 P_LUT[C][LUT0] 25 0 511 Point LUT Value of 6 points - O O
755-424 P_LUT[C][LUT1] 36 0 511 Point LUT Value of 6 points - O O
755-425 P_LUT[C][LUT2] 76 0 511 Point LUT Value of 6 points - O O
755-426 P_LUT[C][LUT3] 112 0 511 Point LUT Value of 6 points - O O
755-427 P_LUT[C][LUT4] 148 0 511 Point LUT Value of 6 points - O O
755-428 P_LUT[C][LUT5] 255 0 511 Point LUT Value of 6 points - O O
755-429 P_LUT[K][LUT0] 25 0 511 Point LUT Value of 6 points - O O
Table 1 NVM 755_Process Control 4 List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description Unit
Write
Allowed/
Protected
Can be
initialized
To Next Page
