DC SC2020
General
6.4.5 Menu Tree
Version 1.1
6.4.5 Menu Tree
• Printer Diag
Table 1 Printer Diag
Top Menu 1st hierarchy 2nd hierarchy 3rd hierarchy 4th hierarchy
CE Mode Printer Diag ESS Diag All Test
FlashROM Test
EEPROM Test
DRAM Test
MAC+PHY Test
ASIC Test
IOT Test
RTC Test
IOT Diag Digital Input
Digital Output
Analog Input
NVM Settings Edit NVM
Clear IOT NVM IOT NVM
Print Info Config Page
Print Settings
Installation Serial No.1
Serial No.2
Serial No.3
Product No.1
Product No.2
Product No.3
HexDump
Tone Correction
Pixel Counter
Configuration Dip Switch 0
Dip Switch 1
Dip Switch 2
Dip Switch 3
Meter Type Type1
Type2
Type3
Type4
Type5
Print Counter Print Service
Copy Service
FAX Service
Scan Service
Copy Counter M to B
Copy Counter B to M
Clear All NVM
Clear Job History
Clear Auditron PV
Clear Device Data
Test Print Total Chart ESS
HT Cyan ESS
HT Magenta ESS
HT Yellow ESS
HT Black ESS
HT CMY ESS
HT CMYK ESS
HT Red ESS
HT Green ESS
HT Blue ESS
Grid2 ESS
Gradation ESS
No Image IOT
Procon OFF ESS
Procon ON ESS
LPH Chart LM1
LPH Chart IBY
ToneUp [C] 5P
ToneUp [M] 5P
ToneUp [Y] 5P
ToneUp [K] 5P
ToneDown [C] 10P
ToneDown [M]10P
ToneDown [Y] 10P
ToneDown [K] 10P
Calibration Chart
Parameter Life Deve HSG PV Y
Deve HSG PV M
Deve HSG PV C
Deve HSG PV K
Table 1 Printer Diag
Top Menu 1st hierarchy 2nd hierarchy 3rd hierarchy 4th hierarchy
To Next Page
