Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-198
DC SC2020
6.4.5 Menu Tree
Version 1.1
General
• Fax/Scanner Diag
Y Drum Ctrg PV
M Drum Ctrg PV
C Drum Ctrg PV
K Drum Ctrg PV
IBT Unit
2nd BTR Unit
Fusing Print Count
Fusing Time Count
Deodorant Filter
EEPROM Write Cnt
Tray1 F/R/N Roll
Tray2 F/R/N Roll
MSI FR Pad
Life Print
Procon Print
RTC Set
Exit Mode Complete Exit
Table 2 Fax/Scanner Diag
Top Menu 1st hierarchy 2nd hierarchy 3rd hierarchy 4th hierarchy
CE Mode Fax/Scanner Diag Board Test All Test
Fax Memory Test Fax Flash W/R Test
MRAM W/R Test
I/F Test Fax Card I/F Test
FX Chip Test (Ready to Start)
Relay/Signal Test Relay Test
Hook Test
Single Tone Send
DTMF Send
Dial Pulse Send
Ring Back Tone
Data Send
Line Voltage
Line Current
Table 1 Printer Diag
Top Menu 1st hierarchy 2nd hierarchy 3rd hierarchy 4th hierarchy
Information Scan Counter
Scanner Mainte-
nance
Scan Counter Clear Counter Clear (FB)
Counter Clear
(DADF)
Auto Shading (Ready to Start)
CVT Auto Shading
(Color)
(Ready to Start)
CVT Auto Shading
(Gray)
(Ready to Start)
LED Calibration (Ready to Start)
Componet Check IIT Input
IIT Output
DADF Componet
Check
DADF IIT Input
DADF IIT Output
DADF Size Detect
Auto Adj.
(Ready to Start)
Parameter Chain Link
Backup Data All Clear
User Clear
System Clear
User & System Clear
System Data Init
Document Clear
DADF Clear
Complete
Table 2 Fax/Scanner Diag
Top Menu 1st hierarchy 2nd hierarchy 3rd hierarchy 4th hierarchy
