05/2014
6-199
DC SC2020
General
6.4.6 CE Mode Functions Overview
Version 1.1
6.4.6 CE Mode Functions Overview
Items available to test or execute the diagnosis in the CE mode are listed in the table below.
Table 1 Function Names and Details (Printer)
Function Description See
ESS Diag All Test All Test Performs all ESS Diag tests except for
MAC+PHY/USB Host/RTC.
6.4.7.1
FlashROM Test Calculates the checksum per Flash ROM header
area and compares the result with the each area’s
prepared checksum stored in the ROM.
6.4.7.2
EEPROM Test EEPROM Test Writes/reads/verifies the test pattern
in the EEPROM area to be evaluated.
6.4.7.3
DRAM Test Writes the test data in the DRAM area to be evalu-
ated. (Values will be overwritten with the original
value afterthe test)
6.4.7.4
MAC+PHY Test MAC+PHY Test Performs the loopback test for MAC
(Media Access Control) and PHY (Physical Layer).
6.4.7.5
ASIC Test Perfoms the Register check test. 6.4.7.6
IOT Test Performs the communication test between IOT. 6.4.7.7
RTC Test Performs the RTC test. 6.4.7.8
IOT Diag Digital Input Digital Input Checks the status of the IOT sensor. 6.4.8.1
Digital Output Digital Output Checks the status of the motor drive. 6.4.8.2
Analog Input Monitors the A/D converted analog value of the sen-
sor while each component is being operated.
6.4.8.3
NVM Set-
tings
Edit NVM Writes the NVM values. 6.4.8.4
Clear IOT NVM Clear the NVM data of IOT. 6.4.8.5
Print Info Config Page Config Page Prints the printer configuration informa-
tion on A4 paper.
6.4.9.1
Print Settings Print Settings Prints the printer setting information on
A4 paper.
6.4.9.2
Installation Serial No. Displays/specifies the serial number. 6.4.10
Product No. Displays the product number.
HexDump Specifies whether to set HexDump to ON or OFF.
Tone Correction
(IOT tone correction)
Specifies whether to set IOT Tone Correction to ON
or OFF.
Pixel Counter Displays the last print pixel coverage (%) for 4 mm
square meter in A4 paper, per Y/M/C/K color.
Configuration Operates the DIP switches on the NVM in ESS.
Meter Type Displays the current information of the MeterType.
Print
Counter
Print Ser-
vice
Displays the current count of the Print Service.
Copy Ser-
vice
Displays the current count of the Copy Service.
FAX Ser-
vice
Displays the current count of the FAX Service.
Scan Ser-
vice
Displays the current count of the Scan Service.
Copy Counter M to B Copies the Master NVM values to the Backup NVM. 6.4.10
Copy Counter B to M Copies the Backup NVM values to the Master NVM. 6.4.10
Clear All NVM Initializes NVM. ESS (EEPROM) of ESS PWB
Clear Job History Initializes the job data (log).
Clear Auditron PV Clear total counter, or user account, restricted infor-
mation, etc.
Clear Device Data Deletes all data in the devices (EEPROM, SRAM,
FaxMemory).
Test Print TotalChart ESS Print delivery inspection chart. HBPL data for built-in
ESS.
6.4.11.2
HT Cyan ESS Print halftone pattern (C) in the PCL6. Density be
specified in increments of 10%. Up to 100%.
6.4.11.3
HT Magenta ESS Print halftone pattern (M) in the PCL6. Density be
specified in increments of 10%. Up to 100%.
6.4.11.4
HT Yellow ESS Print halftone pattern (Y) in the PCL6. Density be
specified in increments of 10%. Up to 100%.
6.4.11.5
HT Black ESS Print halftone pattern (K) in the PCL6. Density be
specified in increments of 10%. Up to 100%.
6.4.11.6
HT CMY ESS Print halftone pattern (CMY) in the PCL6. Density be
specified in increments of 10%. Up to 80%.
6.4.11.7
HT CMYK ESS Print halftone pattern (CMYK) in the PCL6. Density
be specified in increments of 10%. Up to 60%.
6.4.11.8
HT Red ESS Print halftone pattern (R) in the PCL6. Density be
specified in increments of 10%. Up to 100%.
6.4.11.9
HT Green ESS Print halftone pattern (G) in the PCL6. Density be
specified in increments of 10%. Up to 100%.
6.4.11.10
HT Blue ESS Print halftone pattern (B) in the PCL6. Density be
specified in increments of 10%. Up to 100%.
6.4.11.11
Table 1 Function Names and Details (Printer)
Function Description See
To Next Page
