05/2014
6-200
DC SC2020
6.4.6 CE Mode Functions Overview
Version 1.1
General
Grid2 ESS Print ESS built-in grid pattern. This is to check the
print function.
6.4.11.12
Gradation ESS Print ESS built-in tiled pattern C, M, Y, and K from 0
up to 100% density.
6.4.11.13
No Image IOT Print a blank pattern of built-in IOT. This is to check
the IOT print function.
6.4.11.14
Procon OFF ESS Built-in ESS Procon chart with Procon: printed in OFF
mode.
6.4.11.15
Procon ON ESS Built-in ESS Procon chart with Procon: printed in ON
mode.
6.4.11.16
LPH Chart LM1 Print LPH line evaluation chart (LM1) of integrated
IOT.
6.4.11.17
LPH Chart IBY Print LPH line evaluation chart (IBY) of integrated
IOT.
6.4.11.18
ToneUp [C]5P Print Tone up Cyan chart. HBPL data for built-in ESS. 6.4.11.19
ToneUp [M]5P Print Tone up Magenta chart. HBPL data for built-in
ESS.
6.4.11.20
ToneUp [Y]5P Print Tone up Yellow chart. HBPL data for built-in
ESS.
6.4.11.21
ToneUp [K]5P Print Tone up Black chart. HBPL data for built-in ESS. 6.4.11.22
ToneDown [C]10P Print Tone down Cyan chart. HBPL data for built-in
ESS.
6.4.11.23
ToneDown [M]10P Print Tone down Magenta chart. HBPL data for built-
in ESS.
6.4.11.24
ToneDown [Y]10P Print Tone down Yellow chart. HBPL data for built-in
ESS.
6.4.11.25
ToneDown [K]10P Print Tone down Black chart. HBPL data for built-in
ESS.
6.4.11.26
Parameter Life Deve
HSG PV Y
Displays the Print Volume of Deve Unit Y was used. 6.4.12.1
Deve
HSG PV
M
Displays the Print Volume of Deve Unit M was used. 6.4.12.1
Deve
HSG PV
C
Displays the Print Volume of Deve Unit C was used. 6.4.12.1
Deve
HSG PV K
Displays the Print Volume of Deve Unit K was used. 6.4.12.1
Y Drum
Ctrg PV
Displays the Print Volume of Drum Cartridge Y was
used.
6.4.12.1
M Drum
Ctrg PV
Displays the Print Volume of Drum Cartridge M was
used.
6.4.12.1
Table 1 Function Names and Details (Printer)
Function Description See
C Drum
Ctrg PV
Displays the Print Volume of Drum Cartridge C was
used.
6.4.12.1
K Drum
Ctrg PV
Displays the Print Volume of Drum Cartridge K was
used.
6.4.12.1
IBT Unit Displays the Print Volume of IBT Unit was used. 6.4.12.1
2nd BTR
Unit
Displays the Print Volume of 2nd BTR Unit was used. 6.4.12.1
Fusing
Print
Count
Displays the Print Volume of Fusing Unit was used. 6.4.12.1
Fusing
Time
Count
Displays time used with the Fusing Unit. 6.4.12.1
Deodor-
ant Filter
Displays the Print Volume with deodorant Filter. 6.4.12.1
EEPROM
Write Cnt
Displays number of times written to EEPROM. 6.4.12.1
Tray1 F/R/
N Roll
Displays the Print Volume using Tray1 Feed Roll/
Retard Roll/Nudger Roll.
6.4.12.1
Tray2 F/R/
N Roll
Displays the Print Volume using the Tray2 Feed Roll/
Retard Roll/Nudger Roll.
6.4.12.1
MSI FR
Pad
Displays the Print Volume using the MSI Feed Roll/
Retard Pad.
6.4.12.1
Life Print Print the Print Volume using the periodic replacement
parts.
6.4.12.2
Procon
Print
Print current value of NVM used in Procon. 6.4.12.3
ADJ 8.1.5
RTC Set RTC Set Set the RTC (Real Time Clock). 6.4.13
Exit Mode Com-
plete Exit
Exits from the CE Mode and reboots. 6.4.4
Table 2 Function Names and Details (Fax/Scanner)
Function Description See
Board Diag All Test Continually performs the Fax Memory, Fax Card I/F,
AFE Serial I/F, IIT I/F, and ASIC tests.
6.4.14.1
Fax Mem-
ory Test
Fax Flash
W/R Test
Performs write/read tests of the Fax Flash Memory. 6.4.14.2
MRAM
W/R Test
Performs write/read tests of the Fax MRAM. 6.4.14.2
I/F Test Fax Card
I/F Test
Performs the communication test between Fax Card,
AFE, and IIT.
6.4.14.3
FX Chip
Test
Ready to
start
Performs the ASIC built-in IJAC/JBIG test. 6.4.14.4
Table 1 Function Names and Details (Printer)
Function Description See
To Next Page
