6.4.14.5 Relay/Signal Test
Version 1.1
6.4.14.5 Relay/Signal Test
Procedure
The procedure below explains [DTMF Send] > [DTMF Continuous] as an example.
1. Enter the CE mode. (See "6.4.2 How To Enter the CE Mode")
2. Use the [Down arrow] button to select [Fax/Scanner Diag], and press the [OK] button.
Table 1 Relay/Signal Test
Item Range Description
Relay Test Relay Toggle Test 50 - 9999 Toggles the Relay signal within the speci-
fied frequency.
Relay Set Test ON, OFF Outputs the Relay signal at a specified
level.
Hook Test Hook Toggle Test 0150 - 9999 Toggles the Hook signal within the speci-
fied frequency.
Hook Set Test ON, OFF Outputs the Hook signal at a specified
level.
Single Tone
Send
0Hz - Continuously sends the selected frequency
tone.
400Hz
462Hz
1100Hz
1300Hz
1500Hz
2100Hz
500Hz
600Hz
900Hz
1000Hz
DTMF Send DTMF Continuous 0 - 9, A - D, *, # Continuously sends the DTMF signal.
DTMF Individually 16 digits
(each digit 0 - 9, A
- D, *, #)
Sends the multiple digits DTMF signal.
Dial Pulse
Send
DP10 Individually 10 digits
(each digit: 0 - 9)
Sends the multiple digits dial pulse (10pps)
signal.
DP20 Individually 10 digits
(each digit: 0 - 9)
Sends the multiple digits dial pulse (20pps)
signal.
Ring Back Tone - Sends the ringback tone.
Data Send V.34 33600bps - Sends the data specified with speed and
pattern (no pattern for V.34).
V.34 31200bps
V.34 28800bps
V.34 26400bps
V.34 24000bps
V.34 21600bps
V.34 19200bps
V.34 16800bps
V.34 14400bps
V.34 12000bps
V.34 9600bps
V.34 7200bps
V.34 4800bps
V.34 2400bps
V.29 9600bps 5 patterns Sends the data specified with speed and
pattern.
V.29 7200bps
V.27ter 4800bps 5 patterns Sends the data specified with speed and
pattern.
V.27ter 2400bps
V.21 300bps 5 patterns Sends the data specified with speed and
pattern.
V.17 14400bps 5 patterns Sends the data specified with speed and
pattern.
V.17 12000bps
V.17 9600bps
V.17 7200bps
Line Voltage - Checks the Line Voltage status.
Line Current - Checks the Line Voltage status.
Table 1 Relay/Signal Test
Item Range Description
To Next Page
