05/2014
6-266
DC SC2020
6.4.17 Parameter (System Data Setting)
Version 1.1
General
6.4.17 Parameter (System Data Setting)
You can specify the Fax and Scan system data settings.
• 6.3.22 System Data List
• 6.3.3 DADF NVM List
• 6.3.4 IIT NVM List
Procedure
1. Enter the CE mode. (See "6.4.2 How To Enter the CE Mode")
2. Use the [Down arrow] button to select [Fax/Scanner Diag], and press the [OK] button.
3. Use the [Down arrow] button to select [Parameter], and press the [OK] button.
Figure 1 j0bs64138
4. Change the Chain Link number, and press the [OK] button.
• Use the [<-] and [->] buttons to move the cursor to right and left.
• Use the [Up arrow] and [Down arrow] buttons to increase or decrease the value where the cur-
sor is placed.
• Press the [OK] button, and the Chain Link number changed will appear.
Figure 2 j0bs64139
5. Change the setting value, and press the [OK] button.
• * (asterisk) will appear when the value is set.
Figure 3 j0bs64140
6. Press the [<--] (Back) button to return to the [Fax Scanner Diag] screen.
Figure 4 j0bs64141
7. Exit the CE mode. (See "6.4.4 How to Exit the CE Mode")
To Next Page
