05/2014
6-278
DC SC2020
6.6.3 Protocol Monitor
Version 1.1
General
6.6.3 Protocol Monitor
Format Overview
The implication of the symbol which appears in the arrow
In G3 mode, the command for displaying added information in the arrow is displayed.
< [Added Information] -
Example)
< @- , < #-
Implication of added information
Recorded G3 Signal Name and Implication
Table 1
Added Information
Code When sending When receiving
- Normal signal Normal signal
@ Undefined Undefined
X Undefined CRC Error Detection
# Undefined Undefined
! Undefined Carrier disconnected for 1sec in image information
= Undefined Intermittent discontinuity in image information
/ Undefined Undefined
* Undefined Undefined
+ Undefined Undefined
: Undefined Undefined
A Undefined Undefined
B Undefined Undefined
C Undefined Undefined
D Undefined Undefined
E Undefined Undefined
F Undefined Undefined
Table 2
Signal Name Description
CED Called Station Identification Signal
CNG Outgoing Calling Tone
CI Function Display Signal
ANSam Varied Answering Tone
CM Calling Menu Signal
JM Common Menu Signal
CJ CM Terminal Signal
NSF Non-standard Features
CSI Called Station Identification
DIS Digital Identification Signal
NSC Non-Standard Function Command
CIG Calling Terminal Identification
DTC Digital Send Command
SEP Selection Polling
PSA Polling Sub-Address
PWD Password
NSS Non-Standard Function Settings
TSI Transmission Terminal Identification
DCS Digital Command Signal
SUB Sub Address
SID Sending Station Identification
TCF Training Check
CFR Reception Preparation Verification
FTT Training Failed
CTC Correction Continuation (ECM)
CTR Correction Continuation Response (ECM) [Response for CTC]
NSSX Non-Standard Function Settings
TCFX Training Check
PIX Image Information
TRN Training
CPIX Image Information (ECM)
EOM Note
EOP Message Ends
EOS Procedure Ends
MCF Message Confirmation
MPS Multi-Page Signal
PIN Procedure Disruption Reject
PIP Procedure Disruption Affirmation
To Next Page
