05/2014
6-279
DC SC2020
General
6.6.3 Protocol Monitor
Version 1.1
PRI-EOM Procedure Disruption EOM
PRI-MPS Procedure Disruption MPS
PRI-EOP Procedure Disruption EOP
RTN Retraining Reject
RTP Retraining Affirmation
EOR. EOM Resend Ends / Message Ends (ECM)
EOR. EOP Resend Ends / Procedure Ends (ECM)
EOR. MPS Resend Ends / Multi-Page Signal (ECM)
EOR.NULL Resend Ends / Partial Page Boundary (ECM)
EOR.PEOM Resend Ends / Procedure Disruption EOM (ECM)
EOR.PEOP Resend Ends / Procedure Disruption EOP (ECM)
EOR.PMPS Resend Ends / Procedure Disruption MPS (ECM)
ERR Resend Completion Response (ECM) [Response for EOR]
PPR Partial Page Request (ECM)
PPS. EOM Partial Page Signal / Message Ends (ECM)
PPS. EOP Partial Page Signal / Procedure Ends (ECM)
PPS. MPS Partial Page Signal / Multi-Page Signal (ECM)
PPS. NULL Partial Page Signal / Partial Page Boundary (ECM)
PPS. PEOM Partial Page Signal / Procedure Disruption EOM (ECM)
PPS. PEOP Partial Page Signal / Procedure Disruption EOP (ECM)
PPS. PMPS Partial Page Signal / Procedure Disruption MPS (ECM)
RNR Reception Not Allowed (ECM)
RR Reception Allowed (ECM)
EOMX Message Ends (Xerox)
EOR.EOMX Resend Ends / Message Ends (Xerox, ECM)
EOR.MPSX Resend Ends / Multi-Page Signal (Xerox, ECM)
EOR.PEOX Resend Ends / Procedure Disruption EOM (Xerox, ECM)
EOR.PMPX Resend Ends / Procedure Disruption MPS (Xerox, ECM)
MPSX Multi-Page Signal (Xerox)
PPS. EOMX Partial Page Signal / Message Ends (Xerox, ECM)
PPS. MPSX Partial Page Signal / Multi-Page Signal (Xerox, ECM)
PPS. PEOX Partial Page Signal / Procedure Disruption EOM (Xerox, ECM)
PPS. PMPX Partial Page Signal / Procedure Disruption MPS (Xerox, ECM)
PRI-MPSX Procedure Disruption MPS (Xerox)
PRI-EOMX Procedure Disruption EOM (Xerox)
CRP Command Resend
DCN Disconnection Command
Table 2
Signal Name Description
To Next Page
