6.6.4.12 Bit 19, 20 Description
Version 1.1
General
6.6.4.12 Bit 19, 20 Description
UL: Unlimited (Unlimited length=Roll Paper)
LB4: Length of B4 (B4 length)
6.6.4.13 Bit 17, 18 Description
WA3: Width of A3 (A3 Width)
WB4: Width of B4 (B4 Width)
Table 1
UL LB4
Maximum Record Length (Slow Scan
Length)
0 0 A4 length (297mm)
0 1 B4 length (364mm) and A4 length (297mm)
1 0 Unlimited length (Roll Paper)
1 1 Invalid (Selection not allowed)
Table 1
WA3 WB4 Maximum Record Width (Fast Scan Width)
0 0 A4 width (215mm)
0 1 Below B4 width (255mm) (A4 included)
1 0 Below A3 width (303mm) (B4 and A4 included)
1 1 Invalid (Selection not allowed)
