Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-289
DC SC2020
General
6.6.4.18 Bit 25 Description
Version 1.1
6.6.4.18 Bit 25 Description
HSM: 2400BPS Handshaking
0 -> Off
1 -> On
HSM is pertinent to past models. New recommended machine is set to ’0’.
6.6.4.19 Bit 1, 3, 33~38, 47, 49~51, 53~55, 57, 59, 60, 62, 65~71,
73~75, 81~84, 87, 92~95, 97~99, 101, 102 Description
Table 1
Divisio
n Bit No. Item Name
Contents [For DIS/DTC -> 1: With capability, 0: No capability; For
DCS -> 1: Send the relevant signal, 0: Do not send]
I Bit 1 SIM Internet Fax Simple Mode Capability
I Bit 3 REAL Internet Fax Real time Internet Fax
- Bit 33 IGN Invalid Field Signal Capability
F Bit 34 SPC F Code Multiple Selection Polling Capability. DCS is set to 0. (Refer to
the table in 6.6.4.2)
F Bit 35 SUB F-Code Polling Sub Address CapabilityDCS is set to 0.
(Refer to the table in 6.6.4.2)
C Bit 36 T43 Color Fax T.43 Encoding Capability. Select T.43 or JPEG (Bit 68) as the
Encoding Method
C Bit 37 INT Color Fax Plain Interleave Capability. Valid only when Bit 36 is 1.
F Bit 34 SPC F Code Multiple Selection Polling Capability. DCS is set to 0.
(Refer to the table in 6.6.4.2)
F Bit 47 SEP F Code Selection Polling Capability. DCS is set to 0.
(Refer to the table in 6.6.4.2)
F Bit 49 SAC F Code Sub Address Capability
(Refer to the table in 6.6.4.2)
F Bit 50 PWC F Code Password Capability
(Refer to the table in 6.6.4.2)
-Bit
51~51
- File Transfer Capability
-Bit
59~65
- Mixed Mode / Bit 66 and 67
C Bit 68 JPG Color Fax JPEG Encoding Capability. Bit 27 (ECM) is set to 1 if this is
set to 1.
C Bit 69 FC Color Fax Full Color Capability. Valid only when Bit 68 is 1.
C Bit 70 HUF Huffman Code Table Command. Valid only when Bit 68 is 1. DIS is set
to 0. (Change the compression rate based on the Code Table)
C Bit 71 12 12bit/pixel Capability. For 0, image data is 8bit/pixel. Valid only when Bit
68 is 1.
C Bit 73 SAM Color Fax Sub Sampling Disabled (L*, a*, b* is 1: 1: 1). 0 is 4: 1: 1. Valid
only when Bit 68 is 1.
C Bit 74 ILL Color Fax Non-Standard Irradiated Light. 0 uses CIE Standard Irradi-
ated Light D50. Valid only when Bit 68 is 1.
C Bit 75 GAR Color Fax Non-Standard Gamut Range. 0 uses the standard range.
Valid only when Bit 68 is 1.
-Bit 81HKMHKM key
-Bit 82RSARSA key
- Bit 83 OVR Overwrite Mode
