05/2014
6-290
DC SC2020
6.6.4.20 Bit 46 Description
Version 1.1
General
Division Description
6.6.4.20 Bit 46 Description
HMSL: Super High Quality Mode MSL Time (Valid for DIS only)
0 -> T15.4=T7.71 -> T15.4=1/2 T7.7
• If HMSL is ’1’ and T7.7 is 10, 20, 40ms, the linear scan time for Super High Quality Mode is reduced
to 1/2 of High Quality Mode.
• If DIS T7.7 is 0ms or 5ms (Bit 23, 22 and 21 are 111, 001, and 110 respectively), Bit 46 must be set
to ’0’.
- Bit 84 HFX HFX40 Code
- Bit 87 HFI HFX40-I Hashing Capability
-Bit
92~95
T44 Mixed Raster Contents Mode
C Bit 97 C34 Color Fax 300x300, or 400x400 pixels/25.4mm Capability
C Bit 98 C100 Color Fax 100x100 pixels/25.4mm Capability
- Bit 99 BFT Binary File Transfer Capability
I Bit 101 IP Internet Fax Selective Polling. DCS is set to 0.
I Bit 102 IA Internet Fax Routing Address. When used in DCS, other F-Code Bit 49
and 50 may be set to 1.
Table 2
Division Contents
C: Color Fax Scan a color document with a Scanner of 200 dpi or more and encode (com-
press) the image data with 8x8 bits pixel elements (or more) (CIELAB data
Expressed by L*, a*, b*) to JPEG or T43 for transmission purposes. ECM is
required for G3. a*: +Red<->Green- (’+’ value for Red and ’-’ value for Green),
b*: +Yellow<->Blue-(same) CIELAB Data Color Component Sampling L*,a*,b* -
> 4: 1: 1 shows that a*, b* components are reduced to 1/4 of L* component
(Brightness element data).1: 1: 1 indicates that Sub Sampling is not performed
(not thinned out).
Moreover, if only L* component is being used while a*,b* value is set to 0, 0, it
will become BW Fax.
F: F-Code (Refer to Table 2 for F-Code) F-Code Communication also supports password-
protected Mail Box communication with machine of other brands. Registers the
password or sub-address to the receiving station and notifies the setup avail-
ability in DIS.
Add password, sub address, and others in the function frame at the Sending
Station and send. The Receiving station will receive only if the settings match. If
the Sending Station does not have the capability, the frame will not be sent.
T: File Transfer -
M: Mixed Mode -
Table 1
Divisio
n Bit No. Item Name
Contents [For DIS/DTC -> 1: With capability, 0: No capability; For
DCS -> 1: Send the relevant signal, 0: Do not send]
To Next Page
