05/2014
6-291
DC SC2020
General
6.6.4.21 Bit 45 Description
Version 1.1
6.6.4.21 Bit 45 Description
MBR: Meteric Based Resolution Preferred
(mm series resolution capability ... DIS only)
DIS
0 -> Off
1 -> On (DCS is optional)
When Bit 15 is ’1’*
When Bit 43 is ’1’*
* When Bit 41~43 is 0, the contents of Bit 15 becomes valid.
6.6.4.22 Bit 44 Description
IBR: Inch Based Resolution Preferred
(Inch Series Resolution Capability) DIS
0 -> Off
1 -> On
DCS
0 -> mm series
1 -> Inch series
Table 1
MBR IBR
Resolution (relationship between Bit 15 and Bit 43, 44, and
45)
0 0 Invalid (Selection not allowed)
0 1 200x200 pel/inch
1 0 8x7.7 l/mm
1 1 8x7.7l/mm and 200x200pel/inch
Table 2
MBR IBR
Resolution (relationship between Bit 15 and Bit 43, 44, and
45)
0 0 Invalid (Selection not allowed)
0 1 400x400 pel/inch
1 0 16x15.4 l/mm
1 1 16x15.4 l/mm and 400x400 pel/inch
To Next Page
