Fuji Xerox DocuCentre SC2020 - Page 758

7.3 BSD
Chain5 Document Transportation
ABCDEFGHJ
1
2
3
4
5
6
7-20
5.3 DOCUMENT SIZE SENSING (2 OF 2)
j0bs730503
DADF PWB
PL56.2
DADF TRAY SET GUIDE
SENSOR 1
PL56.11
J768
2
15
1
+5VDC
+5VDC
(1.4 F1)
J759
13
J768
3
DC COM
DC COM
(1.4 F3)
DADF PWB
PL56.2
J759
14
+5VDC
BLU
BLU
BLU
DADF TRAY SET
GUIDE SENSOR 1
BLOCKED (H)+5VDC
005-215
DADF TRAY SET GUIDE
SENSOR 2
PL56.11
J767
2
12
1
+5VDC
+5VDC
(1.4 F1)
10
J767
3
DC COM
DC COM
(1.4 F3)
11
+5VDC
BLU
BLU
BLU
DADF TRAY SET GUIDE
SENSOR 3
PL56.11
J766
2
9 1
+5VDC
+5VDC
(1.4 F1)
7
J766
3
DC COM
DC COM
(1.4 F3)
8
+5VDC
BLU
BLU
BLU
DADF TRAY SET
GUIDE SENSOR 2
BLOCKED (H)+5VDC
005-216
DADF TRAY SET
GUIDE SENSOR 3
BLOCKED (H)+5VDC
005-217
DOCUMENT TRAY
SIZE SENSOR 1
(CH5.2)
DADF TRAY SET
GUIDE SENSOR 1
DADF TRAY SET
GUIDE SENSOR 2
DADF TRAY SET
GUIDE SENSOR 3
ELECTRICAL COMPONENTS
DOCUMENT TRAY
SIZE SENSOR 2
(CH5.2)
DADF IIT Input
DADF IIT Input
DADF IIT Input
