Fuji Xerox DocuCentre SC2020 - Page 759

7.3 BSD
Chain5 Document Transportation
ABCDEFGHJ
1
2
3
4
5
6
7-21
5.4 DOCUMENT FEEDING
j0bs730504
DADF PWB
PL56.2
DADF PWB
PL56.2
DADF PRE REGI. SENSOR
PL56.14
J772
2
1
+5VDC
+5VDC
(1.4 F1)
J772
3
DC COM
DC COM
(1.4 F3)
+5VDC
BLU
DC COM
DADF FEED MOTOR
ON +24VDC CLOCK A
DC COM
ON +24VDC CLOCK /A
005-004/005/008/010
005-046/047/048/049
DC COM
ON +24VDC CLOCK B
DC COM
ON +24VDC CLOCK /B
BLU
BLU
BLU
BLU
INTLK +24VDC (A COM)
DADF INTLK
+24VDC
(5.1 G1)
F4
4A
ORN
1
DADF FEED MOTOR
DADF IIT Output [005-047]
DADF IIT Output [005-004]
DADF IIT Output [005-005]
DADF IIT Output [005-008]
DADF IIT Output [005-010]
DADF IIT Output [005-046]
Operation Speed
82.5mm/sec (CW)
110.0mm/sec (CW)
165.0mm/sec (CW)
220.0mm/sec (CW)
DADF IIT Output [005-048]
The operation speed varies depending on
the diag code.
The operation is ON for 50 sec and
automatically goes OFF.
1
FAIL CODE
005-122
DADF Simplex/Side 1
Pre Regi. Sensor On Jam
005-135
DADF Side 2 Pre Regi.
Sensor On Jam
005-147
DADF Pre Regi. Sensor
Off Jam on Inverting
005-197
Prohibit Combine Size
Jam
005-198
Too Short Size Jam
005-199
Too Long Size Jam
005-907
DADF Pre Regi. Sensor
Static Jam
DADF PRE REGI.
SENSOR
DOCUMENT
SENSED (H)+5VDC
005-206
DADF FEED MOTOR
PL56.6
J777
4
6
1
3
MOT
5
2
INTLK +24VDC (B COM)
ORN
005-122
005-135
005-147
005-948
005-198
005-199
005-907
BLU
BLU
J760
5
DADF IIT Output [005-049]
DADF T/A CLUTCH
DADF
PRE REGI.
SENSOR
DADF FEED
MOTOR
ELECTRICAL COMPONENTS
DADF IIT Input
DADF IIT Output
J758
2
DADF FEED
CLUTCH
PL56.7
P780
1
DADF FEED CLUTCH
ON (L)+24VDC
1 2
+24VDC
005-062
DADF IIT Output
DC COM
J780
2
1
ORN
BLU
+24VDC-F7
(1.4 F3)
4
DADF T/A
CLUTCH
PL56.7
P781
1
DADF T/A CLUTCH
ON (L)+24VDC
3 2
+24VDC
005-098
DADF IIT Output
DC COM
J781
2
1
ORN
BLU
+24VDC-F7
(1.4 F3)
82.5mm/sec (CCW)
110.0mm/sec (CCW)
165.0mm/sec (CCW)
220.0mm/sec (CCW)
6
J760
4
J754
1
2
3
4
5
6
005-196
005-942
Not-Supported Doc Size
DADF
005-197
005-196
Size Mismatch Jam
on No Mix-size
NOTE:
DADF FEED
CLUTCH
BLU
BLU
BLU
BLU
005-948
SS-Size Mismatch Jam
on No Mix-size
