Fuji Xerox DocuCentre SC2020 - Page 760

7.3 BSD
Chain5 Document Transportation
ABCDEFGHJ
1
2
3
4
5
6
7-22
5.5 DOCUMENT SCAN, INVERT AND EXIT TRANSPORTATION
j0bs730505
DADF REGI. SENSOR
PL56.14
DADF PWB
PL56.2
DADF PWB
PL56.2
ELECTRICAL COMPONENTS
FAIL CODE
005-123
DADF Simplex/Side 1 Regi. Sensor On Jam
005-125
DADF Regi. Sensor Off Jam
005-131
DADF Invert Sensor On Jam on Inverting
005-132
DADF Invert Sensor On Jam
J773
2
9
1
+5VDC
+5VDC
(1.4 F1)
J760
7
J773
3
DC COM
DC COM
(1.4 F3)
J760
8
+5VDC
BLU
BLU
BLU
DADF REGI. SENSOR
DOCUMENT
SENSED (L)+5VDC
005-110
DADF INVERT SENSOR
PL56.10
J771
2
3
1
+5VDC
+5VDC
(1.4 F1)
1
J771
3
DC COM
DC COM
(1.4 F3)
2
+5VDC
BLU
BLU
BLU
DADF INVERT SENSOR
DOCUMENT
SENSED (L)+5VDC
005-211
DADF REGI. SENSOR
DADF INVERT SENSOR
EXIT NIP RELEASE SOLENOID
005-134
DADF Invert Sensor Off Jam on Inverting
005-136
DADF Side 2 Regi. Sensor On Jam
005-139
DADF Invert Sensor Off Jam
005-145
DADF Regi. Sensor Off Jam on Inverting
005-908
DADF Regi. Sensor Static Jam
005-913
DADF Invert Sensor Static Jam
005-123
005-125
005-131
005-132
005-134
005-136
005-139
005-145
005-908
005-913
DADF IIT Input
DADF IIT Input
J756
2
EXIT NIP
RELEASE
SOLENOID
PL56.7
EXIT NIP RELEASE
SOLENOID
ON (L)+24VDC
1
+24VDC
005-072
DADF IIT Output
DC COM
ORN
BLU
+24VDC-F2
(1.4 F2)
005-130
DADF Invert Sensor On Jam
005-130
