HP PageWide Enterprise Color 556

Figure 1-190 Connect cables
1
2
2. Install the tabs (callout 1) on the front of the control panel in the slots (callout 2) on the printer top
cover.
Figure 1-191 Install the control panel
1
2
150 Chapter 1 Removal and replacement ENWW
