HP PageWide Enterprise Color 556

3. With the front tabs engaged in the slots (callout 1), rotate the control-panel base down onto the printer
(callout 2).
Figure 1-192 Rotate the control-panel base down
2
1
4. Install two # 10 torx screws (callout 1).
Figure 1-193 Install two screws
1
ENWW Removal and replacement procedures 151
