HP PageWide Enterprise Color 556

9. Disconnect one HMDI cable and one connector (callout 1), release the USB cable from the holder and
retainers (callout 2), and then remove two thumbscrews (callout 3).
Figure 1-305 Disconnect connectors and remove thumbscrews
1
3
2
10. Lift the front of the control panel o of the printer (callout 1), and then slide it toward the front of the
printer (callout 2) to remove it.
Figure 1-306 Remove the control panel
2
1
ENWW Removal and replacement procedures 213
