HP PageWide Enterprise Color 556

11. Remove the USB port cover.
Figure 1-307 Remove the USB port cover
12. Remove three screws (callout 1) to release the USB port PCA (callout 2), and then release the cable from
the retainers (callout 3).
Figure 1-308 Remove screws and release the cable
1
2
3
