HP PageWide Enterprise Color 556

2. Install the tabs (callout 1) on the front of the control panel in the slots (callout 2) on the printer top
cover.
Figure 1-417 Install the control panel
1
2
3. With the front tabs engaged in the slots (callout 1), rotate the control-panel base down onto the printer
(callout 2).
Figure 1-418 Rotate the control-panel base down
2
1
270 Chapter 1 Removal and replacement ENWW
