HP PageWide Enterprise Color 556

4. Install two # 10 torx screws (callout 1).
Figure 1-419 Install two screws
1
5. Position the access cover mounting feet into the slots in the top cover (callout 1), and then rotate the
cover down (callout 2) to install it.
NOTE: Press down on the cover rmly to make sure that the tabs (callout 3) snap into place.
Figure 1-420 Install the cover
3
2
1
ENWW Removal and replacement procedures 271
