4. Beginning at the left side of the control-panel cover, carefully release three bosses along the top edge of
the cover.
NOTE: The thin black-plastic cover will separate from the white plastic control-panel base.
Figure 1-660 Release three bosses
5. Lift up on the cover to release the right- and left-side bosses, and then remove the cover.
Figure 1-661 Remove the cover
ENWW Removal and replacement procedures 407
