HP PageWide Enterprise Color 556

6. 586z only: Open the connector latch to release the keyboard at cable.
Figure 1-662 Release the keyboard cable (586z)
1
2
7. 586z MFP only: Slide the keyboard out until it stops, and then release two tabs on the keyboard.
Figure 1-663 Release the keyboard (586z)
408 Chapter 1 Removal and replacement ENWW
