HP PageWide Enterprise Color 556

3. Install two black cables up through the opening in the printer cover.
Figure 1-714 Install two cables through the opening in the cover
4. Install two cables (callout 1) into the retainer (callout 2).
Figure 1-715 Install two cables
2
1
ENWW Removal and replacement procedures 435
