22. 586z only: Insert the Flat cable in the connector, and then close the latch.
TIP: When the at cable is correctly inserted in the connector, the white line on the at cable is parallel
to the connector body.
Figure 1-933 Connect the keyboard cable (586z)
2
1
23. Position the control-panel cover on the control panel.
Figure 1-934 Install the cover
ENWW Removal and replacement procedures 559
