HP PageWide Enterprise Color 556

20. 586z only: Install the keyboard, and then slide it in until it stops.
Figure 1-931 Install the keyboard (586z)
21. 586z only: As the keyboard is installed, pass the at cable (callout 1) through the opening (callout 2) in
the control-panel base.
Figure 1-932 Pass the at cable through the opening
1
2
558 Chapter 1 Removal and replacement ENWW
