3. Insert the at cable in the connector, and then close the latch.
TIP: When the at cable is correctly inserted in the connector, the white line on the at cable is parallel
to the connector body.
Figure 1-58 Connect the keyboard cable
2
1
4. Position the control-panel cover on the control panel.
Figure 1-59 Install the cover
