5. Beginning at the right side of the control-panel cover, carefully push down along the top edge of the
cover to engage the bosses.
NOTE: If the right- and left-side bosses are not fully engaged, push down along the edge of the cover
to fully seat them.
Figure 1-60 Engage three bosses
6. Position the small gray plastic cover in the slot under the control panel, and then push it straight in to
install it.
Figure 1-61 Install the cover
ENWW Removal and replacement procedures 53
