15 - 37
IPN 074-397-P1G
HAPSITE Smart Operating Manual
Figure 15-40 Spraying MicroDuster
12 After the manifold has been leak tested and no leaks found, then the black
cable on the front of the NEG Pump can be plugged into the black socket above
the NEG Pump.
13 In the Tune window, turn the IS Supply and Tune Feed on. See Figure 15-35.
14 At this point, a tune check should be performed on the system. Click on the
Short Tune icon. See Figure 15-41. Refer to section 7.2, Autotune, on page
7-2.
Figure 15-41 Short Tune Icon
15 Follow with section 15.7.6, Part 5: Activation of the NEG Pump, on page 15-38.
