2 - 20
IPN 074-397-P1G
HAPSITE Smart Operating Manual
Figure 2-26 Power Cable Attached at Back Left of the Service Module
The RS232 communication cable is shown in Figure 2-27.
Figure 2-27 RS232 Communication Cable
Attach the RS232 communications cable to the Service Module, as shown in
Figure 2-28.
