6.4 Functions of the exposure screen
HINT
•••••••••••••••••••••••••••••••••••••
• With the REGIUS, REGIUS SIGMA/SIGMA2, items
determined by the inserted CR cassette, "Reading
Size", "Reading Direction", and "Reading Position" are
not displayed.
• The following are displayed in the image display area
where no exposure has been performed.
– Device icon
– Exposure conditions (resolution, size, direction, po-
sition)
• A confirmation screen is displayed when the image
processing related to "Pneumoconiosis" is changed.
•••••••••••••••••••••••••••••••••••••••••••••••••••••
6.4.13 Edit of image supple-
mental information
After exposure, image supplemental information can
be edited.
1
Select images to edit their supplemental
information.
2
Press [Additional].
• The image supplemental information editing
screen is displayed.
3
Edit the image supplemental information.
4
Press [OK].
• The supplemental information is added and the
exposure screen is displayed.
IMPORTANT
•••••••••••••••••••••••••••••••••••••
• Input the patient orientation in the form of [Row orien-
tation]\[Line orientation].
• For the values available for the [Row orientation] and
[Line orientation], refer to the options of the Patient
orientation (Row) and Patient orientation (Line) on the
Exam. Tag edit tool screen.
• To display the Patient orientation (Row) and Patient
orientation (Line), select the property edit tab on the
Exam. Tag edit tool screen, and select the Exam. Tag
master for the master/sub master selection.
• For the details of the Patient orientation (Row) and Pa-
tient orientation (Line), refer to the DICOM Standard.
•••••••••••••••••••••••••••••••••••••••••••••••••••••
