2.1 Overview of this device
This section describes the functions and system conguration example.
2.1.1 Functions
This device is a DIRECT DIGITIZER used with an image diagnosis device, medical imaging device and image stor-
age device c
onnected via the network.
This device digitally processes patient images collected by the medical imaging device to provide image and patient
information.
2.1.2 System conguration example
The system conguration example is as shown below.
X-Ray device operation panel
Printer
PACS
(HOST)
Media
Electronic Medical
Records
DICOM G/W
DICOM
Image Data
DICOM MPPS
DICOM MWM
FTP
X-Ray Exposure
information
DICOM Print
DICOM Storage
JPEG
DICOM PDI
HIS/RIS
REGIUS
REGIUS
SIGMA/SIGMA2
DR
Detector
(1) Order Information
(2) Image Information
(3) Patient Information
CS-7
