Motorola RFS Series User Manual

Common Commands
2-51
2.1.13 interfaces
 Common to all modes
Displays the status of the different switch interfaces
Syntax
show interfaces [WORD|ge|me1|sa|switchport|vlan]
Parameters
Usage Guidelines
Use the show interface command to display the administrative and operational status
of all the interfaces or a specified interface
Example
RFSwitch#show interfaces ge 3
Interface ge3
Hardware Type Ethernet, Interface Mode Layer 2, address is
00-15-70-37-
fa-c1
index=2003, metric=1, mtu=1500, (HAL-IF)
<UP,BROADCAST,MULTICAST>
Speed: Admin Auto, Operational Unknown, Maximum 1G
Duplex: Admin Auto, Operational Unknown
Active Medium: Unknown
Switchport settings: access, access-vlan: 1
Input packets 0, bytes 0, dropped 0,
Received 0 broadcasts, 0 multicasts
Input errors 0, runts 0, giants 0,
CRC 0, frame 0, fragment 0, jabber 0
show interfaces
[WORD|ge|me1|sa|
switchport|vlan]
Displays the interface name
•WORD– Displays interface name
• ge – Displays Gigabit Ethernet interface information
• me1 – Displays fast ethernet information
•sa – Displays Static Aggregate information
• switchport – Displays native VLAN(s) and allowed VLAN
information on switch ports
• vlan[WORD|ge|me1| sa|vlan <1-4094> – Displays VLAN
interface details
