Motorola RFS Series

Global Configuration Commands
5-131
5.1.42 wlan-acl
 Global Configuration Commands
Applies an ACL on a WLAN index
Supported in the following platforms:
• RFS7000
• RFS6000
• RFS4000
Syntax
wlan-acl <1-256> [<1-99>|<100-199>|<1300-1999>|
<2000-2699>|<acl-name>] [in|out]
Parameters
Usage Guidelines 1
Every WLAN created is mapped to an index. When an ACL is applied on a WLAN index it
becomes a WLAN ACL. The following type of ACL’s can be applied on a WLAN:
• IP Standard ACL
• IP Extended ACL
• MAC Extended ACL
When a packet is sent from a client to a WLAN index of an access port, it becomes an
inbound traffic to the wireless LAN.
<1-256> [<1-
99>|<100-
199>|<1300|1999>|
<2000|2699>|word]
[in|out]
WLAN index number
• <1-99> — IP standard access list
• <100-199> — IP extended access list
• <1300-1999> — IP standard access list (expanded
range)
• <2000-2699> — IP extended access list (expanded
range)
• <acl-name> — Access list name
• in — Incoming packets
• out — Outgoing packets
