20-66
20.1.40 qos-mapping
 Wireless Configuration Commands
Configures QoS mappings between the wired and wireless domains
Supported in the following platforms:
• RFS7000
• RFS6000
• RFS4000
Syntax
qos-mapping [wired-to-wireless|wireless-to-wired]
qos-mapping wired-to-wireless [dot1p <0-7>|dscp <0-63>]
[<0-7>|tid0|tid1|tid2|tid3|tid4|tid5|tid6|tid7]
qos-mapping wireless-to-wired
[tid0|tid1|tid2|tid3|tid4|tid5|tid6|tid7] dot1p <0-7>
Parameters
wired-to-wireless [dot1p
<0-7>|dscp <0-63>]
[<0-7>|tid0|tid1|tid2|tid3|
tid4|tid5|tid6|tid7]
Mappings used while switching wired traffic over the air .
• dot1p <0-7> – Configures the mapping of 802.1p tags to
access categories. You can specify more than one 802.1p
tags with in the range 0 and 7
• dscp <0-63> – Configures the mapping of DSCP values to
access categories. You can specify more than one DSCP
values in the range 0-63
• tid0, tid3– best effort category traffic
• tid1, tid2 – background category traffic
• tid4, tid5 – video traffic category traffic
• tid6, tid7 – voice traffic category traffic
