Motorola RF Switch CLI Reference Guide
17-12
Usage Guidelines
Use the mark option to specify the type of service (tos) and priority value. The tos value is
marked in the IP header and the 802.1p priority value is marked in the dot1q frame.
Whenever the interface receives the packet, its content is checked against all the ACEs in
the ACL. It is marked based on the ACL’s configuration.
17.1.6.1 Example - Marking dot1p Priority Value for 802.1q Tagged Traffic
The example below marks the dot1p priority value to 6 for all 802.1q tagged traffic from
VLAN interface 5:
RFSwitch(config-ext-macl)#mark 8021p 6 any any vlan 5 type
8021q
RFSwitch(config-ext-macl)#
17.1.6.2 Example - Marking tos for IP Traffic
The example below marks the tos field to 254 for IP traffic coming from the source MAC :
RFSwitch(config-ext-macl)#mark tos 254 host
00:33:44:55:66:77 any type ip
RFSwitch(config-ext-macl)#
type [8021q|<1-65535>|
arp|appletalk|ip|ipv6ipx|rarp|
vlan|wisp]
Defines an ethertype value represented as an
integer or keyword for well-known ethertypes (like
IP, IPv6, ARP etc.)
vlan <1-4095> Defines the VLAN tag ID to match
dscp <0-63> Modify DSCP TOS bits in IP header
• xx:xx:xx:xx:xx:xx/
xx:xx:xx:xx:xx:xx – Destination MAC
address and mask
• any – Any destination host
• host – Exact destination MAC address to match
