Motorola RFS Series User Manual

Interface Instance
12-33
12.1.19 static-channel-group
 Interface Config Commands
Adds an interface to a static channel group
Displays current system information running on the switch.
Supported in the following platforms:
• RFS7000
• RFS4000
Syntax
static-channel-group <1-4>
Parameters
Usage Guidelines
This command aggregates individual giga ports into a single aggregate link to provide
greater bandwidth. The static channel group is used to provide additional bandwidth in
multiples of 1Gbps on the switch. All MAC layer and higher protocols see only the static
channel group (aggregate link) rather than the individual ports that comprise it.
Example
RFSwitch(config-if)#static-channel-group 2
RFSwitch(config-if)#
SWITCH NOTE: RFS6000 does not support this command
<1-4> Sets a static channel group to associate the link with
