Motorola RF Switch CLI Reference Guide
5-124
Parameters
Example
RFSSwitch(config)#traffic-shape class 1 max-buffers 1000
1000 1000 1000 500 500 500 500 red-level 750 750 750 750 375
375 375 375
RFSSwitch(config)#traffic-shape class 1 max-latency 1000
1000 1000 1000 1000 1000 1000 1000 msec
RFSSwitch(config)#traffice-shape class 1 rate 100000 Kbps
RFSSwitch(config)#traffic-shape priority-map 1 2 0 7 5 3 6 4
class <class-identifier>
max-buffers ... red-level
...
class <class-identifier>
max-buffers ... red-
percent ...
class <class-identifier>
max-latency ...
[msec|usec]
class <class-identifier>
rate {[Kbps|Mbps|bps]}
Traffic shaping packet class. Select an identifier between
1-4. Traffic shaping also uses queues numbered 0-7
• max-buffers – Maximum traffic-shape queue length in
packets
• <1-2000> – Maximum length of lowest or all priority
queues
• red-level – Performs RED (random early drop) when
the queue length is reached
• red-percent – Performs RED (random early drop) at a
percentage of max-buffers
• max-latency – Maximum packet delay in queue.
• <1-1000000> – Maximum latency of lowest or all
priority queues
• [msec|usec] – Sets the time measure
• rate <1-250000000> – Traffic rate (250 Kbps-250 Mbps).
• Kips – Units of kilobits/sec
• Mbps – Units of megabits/sec
• bps – Units of bits/sec
priority-map <0-7> <0-7>
...
Sets 802.1p to priority queue maps for all the traffic shape
queues.
