Wireless Instance
20-137
nac-server
[primary|secondary|
timeout]
Configure a NAC server IP address and an optional
authentication port number.
[primary|secondary] [<IP> {auth-port <port>}|radius-key
[0 <secret>|2 <secret>|<secret>]] – Primary server or
secondary server’s IP address
<IP> {auth-port <port>} – Set an EAP server IP address
and optional EAP server authentication port (default:
is 1812)
radius-key [0 <secret>|2 <secret>|<secret>] – Create a
Radius server shared secret, up to 127 characters
0 <secret> – Password is specified as unencrypted
2 <secret> – Password is encrypted with password-
encryption secret
<secret> – Configures a NAC server shared secret
timeout <1-300> retransmit <1-100> – Sets the time the
switch waits for a response from the RADIUS server
before retrying. This is a global setting for both the
primary and secondary servers. The default timeout is 3
sec.
retransmit <1-100> – Number of retries before the
wireless switch will give up and disassociate mobile
unit
<1-100> – Retry count. The default value is 3.
Note: The RFSwitch(config-wireless)# nac-server
timeout<*> retransmit<*>
should be less than what is
defined for an MU’s timeout and retries. If the MU’s time is
less than the server’s, a fallback to the secondary server will
not work.
nas-id <nas-id> The nas-id of this wlan to be sent to the RADIUS server.
Maximum length of 256 characters.
nas-port-id <port> The nas-port-od of this wlan to be sent to the RADIUS
server. Maximum length of 256 characters.
