Wireless Instance
20-139
• rate-limit [wired-to-wireless|wireless-to-wired]
<100-1000000> – Sets traffic rate limit for users on the
selected WLAN
• wired-to-wireless – Down link direction - from network
to wireless client
• wireless-to-wired – Up link direction - from wireless
client to network
• <100-1000000> – The rate to limit to in kbps
• svp enable – Enables support for Spectralink Voice
Prioritization
• weight <1-10> – The egress weight (relative priority to
other WLANs) of this WLAN. The weight sets the priority
for the packets to be sent
• wmm [8021p|background|best-effort|dscp|video|voice] –
Sets the 802.11e / Wireless Multi Media (WMM)
parameters (supported on AP300,AP650 & AAP5131)
• 8021p – Use 802.1p frame priority (field in the VLAN
tag) to determine packet priority
• dscp –Use Differentiated Services Code Point (DSCP)
bits in the IP header to determine packet priority
• background [aisfn <2-15>|cw <0-15> <0-15>|txop-limit
<0-65535>] – Sets the parameters for background
traffic
• best-effort [aisfn <2-15>|cw <0-15> <0-15>|txop-limit
<0-65535>] – Sets the parameters for normal traffic
• video [aisfn <2-15>|cw <0-15> <0-15>|txop-limit <0-
65535>] – Sets the parameters for video traffic
• voice [aisfn <2-15>|cw <0-15> <0-15>|txop-limit <0-
65535>] – Sets the parameters for voice traffic
