1.3 Driver standard specifications
Model: LECSN2-T
□
5
7
8
9
Output
Rated voltage
3-phase 170 V AC
Rated current
[A]
1.1
1.5
2.8
5.8
Output frequency
Less than 590 Hz
Output frequency accuracy
±0.01%
Main circuit power
supply
Voltage/Frequency
3-phase or 1-phase 200 V AC to 240 V AC, 50 Hz/60 Hz
Rated current
[A]
0.9
1.5
2.6
3.8
Permissible voltage
fluctuation
3-phase or 1-phase 170 V AC to
264 V AC
Permissible frequency fluctuation
Within ±5%
Power supply capacity
[kVA]
Refer to section 10.2.
Inrush current
[A]
Refer to section 10.5.
Control circuit power
supply
Voltage/Frequency
1-phase 200 V AC to 240 V AC, 50 Hz/60 Hz
Rated current
[A]
0.2
Permissible voltage
fluctuation
1-phase 170 V AC to 264 V AC
Permissible frequency fluctuation
Within ±5%
Power consumption
[W]
30
Inrush current
[A]
Refer to section 10.5.
Interface power supply
Voltage
24 V DC ± 10%
Current capacity [A]
(Note 1) 0.3 (including CN8 connector signals)
Control method
Sine-wave PWM control, current control method
Dynamic brake
Built-in
Communication
function
USB: connection to a personal computer or others
(setup software (MR Configurator2
TM
)-compatible)
Encoder output pulses
Compatible (A/B/Z-phase pulse)
Analog monitor
Two channels
Protective functions
Overcurrent shut-off, regenerative overvoltage shut-off,
overload shut-off (electronic thermal), servo motor overheat
protection, encoder error protection, regenerative error
protection, undervoltage protection, instantaneous power
failure protection, overspeed protection, error excessive
protection
Safety function
STO (IEC/EN 61800-5-2)
Safety performance
Standards certified by CB
EN ISO 13849-1 category 3 PL e, EN 61508 SIL 3, EN 62061
SIL CL 3, and EN 61800-5-2
Response performance
8 ms or less (STO input off → energy shut off)
(Note 3)
Test pulse input (STO)
Test pulse interval: 1 Hz to 25 Hz
Test pulse off time: Up to 1 ms
Mean time to dangerous failure (MTTFd)
MTTFd ≥ 100 [years]
Diagnosis coverage (DC)
DC = Medium, 97.6 [%]
Average probability of dangerous failures
per hour (PFH)
PFH = 6.4 × 10
-9
[1/h]
Compliance to global
standards
CE marking
LVD: EN 61800-5-1
EMC: EN 61800-3
MD: EN ISO 13849-1, EN 61800-5-2, EN 62061
UL standard
UL 508C
Structure (IP rating)
Natural cooling,
open (IP20)
Force cooling,
open (IP20)
Close mounting (Note 2)
Possible
Environment
Ambient temperature
Operation
0 ˚C to 55 ˚C (non-freezing)
Storage
-20 ˚C to 65 ˚C (non-freezing)
Ambient humidity
Operation
5% to 90 %RH (non-condensing)
Storage
Ambience
Indoors (no direct sunlight),
free from corrosive gas, flammable gas, oil mist, dust, and dirt
Altitude
2000 m or less above sea level(note7)
Vibration resistance
5.9 m/s
2
, at 10 Hz to 55 Hz (directions of X, Y and Z axes)
Mass
[kg]
1.0
1.4
