17 - 16
17．HOW TO USE INDEXER
17.4.2 JOG operation
(1) Setting
According to the purpose of use, set objects and parameters as shown below. In this case, "Target point
table" is disabled.
Item
Object/parameter to be used
Setting
Jog mode (jg) selection
Modes of operation
Set "-100".
JOG operation selection
[Pr. PT27]
Select "_ _ 1 _" (JOG operation).
Servo motor speed
Profile velocity
Set the servo motor speed.
Acceleration time constant
Profile Acceleration
Set the acceleration time constant.
Deceleration time constant
Profile deceleration
Set the deceleration time constant.
Speed limit
Max profile velocity
Set a speed limit value for during operation.
(2) Operation
Turning on "Controlword bit 4 (Rotation start)" will start rotation to a direction specified with "Controlword
bit 5 (Direction)", and turning off "Controlword bit 4 (Rotation start)" will make deceleration to a stop
regardless of the station position.
Item
Object to be used
Setting
Rotation direction selection
Controlword
Set the rotation direction in "Controlword bit 5
(Direction)". The setting is shown as follows:
Off: Station No. decreasing direction
On: Station No. increasing direction
Start/stop
Controlword
Set start/stop in "Controlword bit 4 (Rotation
start)". The setting is shown as follows:
On: start
Off: decelerate to a stop regardless of the
station position
