20．PROFINET COMMUNICATION
20.9.3.5 Manufacturer Specific Control Objects
(1) External Output pin display (P11281)
The ON/OFF state of external output pins output from the driver can be read.
PNU
Sub
Access
Name
Data Type
Description
Default
11281
0
R
External Output pin
display1
Integer32
External output pin status 1
PNU
Sub
Range
Units
EEP-ROM
Parameter
11281
0
00000000h to 0000000Fh
Impossible
The following shows the detail of External Output pin display1. When the output of the target pin is on, "1"
is returned. When the output of the target pin is off, "0" is returned.
The values in the areas marked with diagonal lines at reading is undefined.
Bit
CN3 connector pin
Bit
CN3 connector pin
Bit
CN3 connector pin
Bit
CN3 connector pin
0
13
8
16
24
1
15
9
17
25
2
9
10
18
26
3
8
11
19
27
4
12
20
28
5
13
21
29
6
14
22
30
7
15
23
31
(2) Machine diagnostic status (P11296)
The current status of machine diagnostic can be obtained. Refer to section 8.9 for details.
PNU
Sub
Access
Name
Data Type
Description
Default
11296
0
R
Machine diagnostic status
Unsigned16
Machine diagnostic status
PNU
Sub
Range
Units
EEP-ROM
Parameter
11296
0
Refer to the text.
Impossible
