20 - 10

20．PROFINET COMMUNICATION

20.2.4 Ethernet cable connection

POINT

Use a twisted pair cable (double shielded) compliant with Ethernet Category 5e

(100BASE-TX) or higher as an Ethernet cable. The maximum cable length

between nodes is 100 m.

When the RJ45 PROFINET communication ports (port 1 and port 2) are not used, leave these ports open.

Controller

The first axis

servo amplifier

Ethernet cable

Port 1

Port 2

The second axis

servo amplifier

Port 1

Port 2

Ethernet cable

The final axis

servo amplifier

Port 1

Port 2

driver

Upper

side
