20 - 175
20．PROFINET COMMUNICATION
(b) Bit mask (P24830: 2)
Bit
Description
0 to 16
(reserved) (Note)
17
DO1
0: DOA (General-purpose output A) disabled
1: DOA (General-purpose output A) enabled
When this bit is set to "0", bit 17 of the Physical outputs is always "0".
18
DO2
0: DOB (General-purpose output B) disabled
1: DOB (General-purpose output B) enabled
When this bit is set to "0", bit 18 of the Physical outputs is always "0".
19
DO3
0: DOC (General-purpose output C) disabled
1: DOC (General-purpose output C) enabled
When this bit is set to "0", bit 19 of the Physical outputs is always "0".
20 to 31
(reserved) (Note)
Note.
The values in bit 0 to 16 and 20 to 31 at reading are undefined.
20.9.3.15 Touch Probe Function Objects
(1) Details of Touch probe function (P24760)
Set the command for the touch probe function. Refer to section 8.6 (2) for details.
PNU
Sub
Access
Name
Data Type
Description
Default
24760
0
R/W
Touch probe function
Unsigned16
Settings such as enabling/disabling of the
touch probe function and trigger conditions
0
PNU
Sub
Range
Units
EEP-ROM
Parameter
24760
0
0000h to FFFFh
Impossible
(2) Touch probe status (P24761)
The status of the touch probe function is returned. Refer to section 8.6 (3) for details.
PNU
Sub
Access
Name
Data Type
Description
Default
24761
0
R
Touch probe status
Unsigned16
Status information of the touch probe
function
PNU
Sub
Range
Units
EEP-ROM
Parameter
24761
0
0000h to FFFFh
Impossible
(3) Touch probe pos1 pos value (P24762)
The position latched at the rising edge of touch probe 1 is returned.
PNU
Sub
Access
Name
Data Type
Description
Default
24762
0
R
Touch probe pos1 pos
value
Integer32
Shows the rising edge position of Touch
probe 1. (command unit)
0
PNU
Sub
Range
Units
EEP-ROM
Parameter
24762
0
80000000h to 7FFFFFFFh
pos units
Impossible
