20．PROFINET COMMUNICATION
(4) Touch probe pos1 neg value (P24763)
The position latched at the falling edge of touch probe 1 is returned.
PNU
Sub
Access
Name
Data Type
Description
Default
24763
0
R
Touch probe pos1 neg
value
Integer32
Shows the falling edge position of Touch
probe 1. (command unit)
0
PNU
Sub
Range
Units
EEP-ROM
Parameter
24763
0
80000000h to 7FFFFFFFh
pos units
Impossible
(5) Touch probe pos2 pos value (P24764)
The position latched at the rising edge of touch probe 2 is returned.
PNU
Sub
Access
Name
Data Type
Description
Default
24764
0
R
Touch probe pos2 pos
value
Lower software
position limit
Shows the rising edge position of Touch
probe 2. (command unit)
0
PNU
Sub
Range
Units
EEP-ROM
Parameter
24764
0
80000000h to 7FFFFFFFh
pos units
Impossible
(6) Touch probe pos2 neg value (P24765) (Drive Configuration Object)
The position latched at the falling edge of touch probe 2 is returned.
PNU
Sub
Access
Name
Data Type
Description
Default
24765
0
Get
Touch probe pos2 neg
value
Lower software
position limit
Shows the falling edge position of Touch
probe 2. (command unit)
0
PNU
Sub
Range
Units
EEP-ROM
Parameter
24765
0
80000000h to 7FFFFFFFh
pos units
Impossible
