SMC Networks LECSN-T Series User Manual

5. PARAMETERS
5 - 3
5.1.1 Basic setting parameters ([Pr. PA_ _ ])
No.
Symbol
Name
Initial
value
Unit
Operation
mode
Standard
PA01
**STY
Operation mode
1000h
PA02
**REG
Regenerative option
0000h
PA03
*ABS
Absolute position detection system
0000h
PA04
*AOP1
Function selection A-1
2000h
PA05
For manufacturer setting
10000
PA06
*CMX
Electronic gear numerator/Number of gear teeth on machine side
1
PA07
*CDV
Electronic gear denominator/Number of gear teeth on servo motor side
1
PA08
ATU
Auto tuning mode
0001h
PA09
RSP
Auto tuning response
16
PA10
INP
In-position range
1600
[pulse]
PA11
TLP
Forward rotation torque limit/
1000.0
[%]
PA12
TLN
Reverse rotation torque limit/
1000.0
[%]
PA13
For manufacturer setting
0000h
PA14
*POL
Rotation direction selection/
0
PA15
*ENR
Encoder output pulses
4000
[pulse/rev]
PA16
*ENR2
Encoder output pulses 2
1
PA17
**MSR
Servo motor series setting
0000h
PA18
**MTY
Servo motor type setting
0000h
PA19
*BLK
Parameter writing inhibit
00ABh
PA20
*TDS
Tough drive setting
0000h
PA21
*AOP3
Function selection A-3
0001h
PA22
**PCS
Position control composition selection
0000h
PA23
DRAT
Drive recorder arbitrary alarm trigger setting
0000h
PA24
AOP4
Function selection A-4
0000h
PA25
OTHOV
One-touch tuning - Overshoot permissible level
0
[%]
PA26
*AOP5
Function selection A-5
0000h
PA27
For manufacturer setting
0000h
PA28
0000h
PA29
0000h
PA30
0000h
PA31
0000h
PA32
0000h
