5.2.7 Positioning control parameters ([Pr. PT_ _ ])
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PT01
**CTY
Command
mode
selection
_ _ _ x
For manufacturer setting
0h
_ _ x _
0h
_ x _ _
Position data unit
0: mm
1: inch
2: degree
3: pulse
This function will be enabled in the profile mode and point table method. The unit is
[pulse] in the cyclic synchronous mode. In the cyclic synchronous mode, setting
other values than "3" will trigger [AL. 37]. If "2" is set in the point table method, [AL.
37] will occur.
3h
x _ _ _
For manufacturer setting
0h
