5. PARAMETERS

5 - 16

5.1.8 Network setting parameters ([Pr. PN_ _ ])

No.

Symbol

Name

Initial

value

Unit

Operation

mode

Standard

PN01

**NADR

Node address setting

0000h

PN02

CERT

Sync Error Counter Limit setting

(Note)

PN03

For manufacturer setting

0000h

PN04

0000h

PN05

0000h

PN06

*NOP1

Function selection N-1

0000h

PN07

For manufacturer setting

0000h

PN08

0000h

PN09

0000h

PN10

0000h

PN11

0000h

PN12

0000h

PN13

0000h

PN14

0000h

PN15

0000h

PN16

0000h

PN17

0000h

PN18

0000h

PN19

0000h

PN20

0000h

PN21

0000h

PN22

0000h

PN23

0000h

PN24

0000h

PN25

0000h

PN26

0000h

PN27

0000h

PN28

0000h

PN29

0000h

PN30

0000h

PN31

0000h

PN32

0000h

Note.

Refer to the function column of [Pr. PN02] for details.
